PRODUCT SPECIFICATIONS

Model	NG300	NG500
Nitrogen flow	300ml/min	500ml/min
Nitrogen purity	99.999%	99.999%
Pressure	4bar	4bar
Size	400×200×300（mm）	400×200×300（mm）

Features

Automatic tracking of output traffic

Equipped with overpressure protection and anti liquid device

LED digital display

Anti impact and anti-aging filter

High purity of gas production

Purity does not decay

Long service life and easy maintenance

Use field

1.Carrier gas for various name brands Gas Chromatography and detectors.
2.ECD Makeup gas
3.Gas Chromatography Purge gas
2.Supplementary gas.
3.Carrier gas for OTR instrument
4.Carrier gas for WVTR instrument
5.Other pure N2 application

Note:user should prepare air compressor with pressure bigger than 4bar,air flow rate should be bigger than 5L/min.

this nitrogen purity is very high enough to be used as the carrier gas of gas chromatography.

this nitrogen generator is based on electrolysis chemical theory to produce pure hydrogen.namely,it firstly electrolysis water to get pure hydrogen,then let the pure hydrogen reaction with oxygen of compressed air.surely,this reaction can only rise in special catalyst room of the nitrogen generator.the catalyst reaction room is the key technology of this nitrogen generator.but the disadvantages of this nitrogen generator is it don’t have built in air compressor.

its size and weight is very small which is very suitable for placing on the lab bench.

we also manufacture PSA based 99.999% purity nitrogen generator with built-in oil free air compressor.

besides nitrogen generator,we also manufacture lab pure hydrogen generators and zero air generators and oil free compressed dry air generators.we also manufacture ultrapure deionized water purification system.
